BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing

  • 1
  • 2
  • 3

Brand Name : XZH TEST

Model Number : XHDD503C

Certification : CE ISO

Place of Origin : China

MOQ : 1 Uuit

Payment Terms : T/T

Delivery Time : 5-8 work days

Packaging Details : wooden packaging

Product name : Cable fault locator

Application : Widely

Channel gain : 8 adjustable

Magnetic channel gain : 8 adjustable

Output gain : Output gain

Output impedance : 350Ω

Volume : 428L*350W*230H

Weight : 6KG

HS Code : 9031809090

Contact Now

XHDD 503C Cable Faults Pin-pointer

Product Description
XHDD503 C The cable fault locating instrument is used to determine the fault point of power cable by acoustic and magnetic synchronous method. With the help of the shock discharge generator to generate electronic flasover, picked up and amplified by the corresponding probe, by auditory and visual judgment, to determine the exact location of the fault point, complete the precise positioning of the cable fault point within the rough measurement range of the equipment, set the acoustic magnetic time difference positioning technology, path assisted testing and other technologies in one, provide a variety of test modes and a variety of tips. Efficiently and accurately locate cable faults.
Features
1, 5 inch touch bright LCD, ensure visible in the sun.
2, the use of acoustic magnetic synchronous positioning technology, automatic calculation of acoustic magnetic time difference.
3, the gain value and trigger value of the acoustic signal and magnetic signal are manually adjusted to adapt to a variety of environmental fixed points.
4, with background noise reduction technology, you can choose a variety of filtering methods.
5, with BNR background noise reduction and mute noise reduction function.
6, with path deviation indication.
7, equipped with multi-layer physical isolation signal sensor, waterproof class IP65.
8, built-in large capacity lithium battery, long standby time, with fast charger.
9, compact and light, easy to operate, easy man-machine interface.

BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing

All pass 100Hz~1600Hz
Low pass 100Hz~300Hz
High pass 160Hz~1600Hz
Band pass 200Hz~600Hz
Maximum signal gain >=112dB
Fixed point accuracy 0.2m
Battery 4*18650 standard lithium battery
Use time Continuous use time > 8 hours
Charging time <6 hours.
Ambient temperature -10℃-55℃, humidity 5-90%RH, altitude <4500m.


BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing

BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing

BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing

BNR Compass Indication for Underground Cable Fault Pinpionter Cable Fault Pinpointing
